QX-Motor 70mm 12-Blade EDF Unit With QF2827 1800KV 2600KV Brushless Motor For RC Airplane Jet
Specifications: Brand Name: QX-Motor Item Name: 70mm 12-Blade EDF Unit Motor: QF2827 KV: 1800KV, 2600KV (optional) Configuration: 9N6P Shaft Diameter: ╬Ğ4.0mm Motor Diameter: 28mm Weight: 175g Working Voltage(Lipo): 6S Max Continuons Power/10s: 1500W Max...
🟢 In Stock
✔️ WORLDWIDE SHIPPING
✔️ 30 DAYS RETURN GUARANTEE
✔️ SECURE CHECKOUT
Description
Specifications:
Brand Name: QX-Motor
Item Name: 70mm 12-Blade EDF Unit
Motor: QF2827
KV: 1800KV, 2600KV (optional)
Configuration: 9N6P
Shaft Diameter: ╬Ğ4.0mm
Motor Diameter: 28mm
Weight: 175g
Working Voltage(Lipo): 6S
Max Continuons Power/10s: 1500W
Max Continuons Current/10s: 65A
Test Data:
| KV | Volts(V) | Amps(A) | Watts(W) | Thrust(g) | Thrust(oz) |
Efficiency(g/W) | Efficiency(oz/W) |
Throttle | ESC |
|
2600KV |
16 | 62.0 | 992 | 1800 | 63.49 | 1.81 | 0.06 | 100% | 80A |
|
1800KV |
25 | 37.0 | 925 | 1927 | 67.97 | 2.08 | 0.07 | 100% | 60A |
English Manual, Click Here
Package Included:
1x QX-Motor 70mm 12-Blade EDF Unit With QF2827 Brushless Motor
QX-Motor 70mm 12-Blade EDF Unit With QF2827 1800KV 2600KV Brushless Motor For RC Airplane Jet
$49.99
