3pcs ME2-CO-14x14 Carbon Monoxide Gas Sensor CO Sensor 0~1000 ppm for Civilian Area to Detect CO Concentration Carbon Monoxide Meter CO Alarms
>>>Manual: Click here to open<<< Principle Introduction: Winsen Electronics, produces Carbon monoxide sensor CO gas sensor, with low cost and fuel cell working principle. ME2-CO-ºñ14x14, fuel cell type sensor, detects...
🟢 In Stock
✔️ WORLDWIDE SHIPPING
✔️ 30 DAYS RETURN GUARANTEE
✔️ SECURE CHECKOUT
Description
Principle Introduction:
Winsen Electronics, produces Carbon monoxide sensor CO gas sensor, with low cost and fuel cell working principle.
ME2-CO-ºñ14x14, fuel cell type sensor, detects gas concentration by measuring current based on the electrochemical principle, which utilizes the electrochemical oxidation process of target gas on the working electrode inside the electrolytic cell, the current produced in electrochemical reaction of the target gas are in direct proportion with its concentration while following Faraday law, then concentration of the gas could be get by measuring value of current.
Applications :
Widely used in civilian area to detect CO concentration.
Technical Parameters :
| Item | Parameter |
| Detection gas | CO |
| Measurement Range | 0´¢Ş1000ppm |
| Max detecting concentration | 2000ppm |
| Sensitivity | ´╝ê3.6´¢Ş9´╝ënA/ppm |
| Resolution ratio | 1ppm |
| Response time´╝êT90´╝ë | Ôëñ30S |
| Load resistance´╝êrecommend´╝ë | 1000╬® |
| Repeatability | ´╝£3´╣¬output value |
| Stability´╝ê´╝Åmonth´╝ë | ´╝£10´╣¬ |
| Output Linearity | linear |
| Zero drift´╝ê-20Ôäâ´¢Ş40Ôäâ´╝ë | Ôëñ10ppm |
| Storage temperature | -20Ôäâ´¢Ş50Ôäâ |
| Storage Humidity | 15%~ 90%RH |
| Pressure range´╝êkPa´╝ë | normal atmosphere ┬▒10% |
Package Included:
3 x ME2-CO-ºñ14x14 Carbon Monoxide Gas Sensor CO Sensor 0~1000 ppm
